IE3 15KW Induction Motor 160L-4 AC Electric Motor with 380V Squirrel Cage AC Electric motor

Product Categories

Bimo Machinery Co.,Limited

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

IE3 15KW Induction Motor 160L-4 AC Electric Motor with 380V Squirrel Cage AC Electric motor

Ask Lasest Price
Brand Name :	BM
Model Number :	IE2
Certification :	CE
Price :	USD38-USD680
Payment Terms :	T/T
Supply Ability :	1000pcs per day
Delivery Time :	Usually within 30 days

Add to Cart

Product Details
Company Profile

IE3 15KW Induction Motor 160L-4 AC Electric Motor with 380V Squirrel Cage AC Electric motor

IE3 15KW Induction Motor 160L-4 AC Electric Motor with 380V Squirrel Cage AC Electric motor

IE3 SERIES THREE PHASE ELECTRIC MOTOR

Frame number: 80 ~ 355 Power: 0.55 ~ 355KW

Working system: S1

Applications: General purpose including cutting, machine, pumps, fans, conveyors, Agricultural Machinery and food machinery
Features:Good-looking appearance, High efficiency and energy saving, low noise and little vibration. F insulation class, IP54 or IP55 protection class

OPERATING CONDITIONS:
Ambient temperature: -15senti degree≤ 0≤ 40senti degree
Altitude: Not exceeding 1000 meters
Rated voltage: 380V, 220/380V, 380/660V, 400V, 415V
Rated frequency: 50Hz / 60 Hz

Output	MODEL	Current	Speed	Eff.	Power factor	Tst	LST	T MAX	Noise聽
(KW)	MODEL	(A)	(r/min)	%	P.F	IN	IN	TN	dB(A)
380V 50HZ 4P
0.55	IE3-80M1-4	1.4	1430	80.8	0.75	3.7	-	-	-
0.75	IE3-80M2-4	1.8	1430	82.5	0.75	2.3	6.6	2.3	56
1.1	IE3-90S-4	2.6	1430	84.1	0.76	2.3	6.8	2.3	59
1.5	IE3-90L-4	3.5	1430	85.3	0.77	2.3	7	2.3	59
2.2	IE3-100L1-4	4.8	1440	86.7	0.81	2.3	7.6	2.3	64
3	IE3-100L2-4	6.3	1440	87.7	0.82	2.3	7.6	2.3	64
4	IE3-112M-4	8.4	1455	88.6	0.82	2.2	7.8	2.3	65
5.5	IE3-132S-4	11.2	1465	89.6	0.83	2	7.9	2.3	71
7.5	IE3-132M-4	15	1465	90.4	0.84	2	7.5	2.3	71
11	IE3-160M-4	21.5	1470	91.4	0.85	2.2	7.7	2.3	73
15	IE3-160L-4	28.8	1470	92.1	0.86	2.2	7.8	2.3	73
18.5	IE3-180M-4	35.3	1470	92.6	0.86	2	7.8	2.3	76
22	IE3-180L-4	41.8	1470	93	0.86	2	7.8	2.3	76
30	IE3-200L-4	56.6	1475	93.6	0.86	2	7.3	2.3	76
37	IE3-225S-4	69.6	1480	93.9	0.86	2	7.4	2.3	78
45	IE3-225M-4	84.4	1480	94.2	0.86	2	7.4	2.3	78
55	IE3-250M-4	103	1485	94.6	0.86	2.2	7.4	2.3	79
75	IE3-280S-4	136	1490	95	0.88	2	6.9	2.3	80
90	IE3-280M-4	163	1490	95.2	0.88	2	6.9	2.3	80
110	IE3-315S-4	197	1490	95.4	0.89	2	7	2.2	88
132	IE3-315M-4	236	1490	95.6	0.89	2	7	2.2	88
160	IE3-315L1-4	285	1490	95.8	0.89	2	7.1	2.2	88
200	IE3-315L2-4	352	1490	96	0.9	2	7.1	2.2	88
220	IE3-315M1-4	387	1490	96	0.9	2	7.1	2.2	95
250	IE3-355M2-4	440	1490	96	0.9	2	7.1	2.2	95
280	IE3-355L1-4	492	1490	96	0.88	2	7.1	2.2	95
315	IE3-355L2-4	554	1490	96	0.88	2	7.1	2.2	95

FAQ

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
