NEMA Premium Efficiency Motor 2 Pole 4 Pole 6 Pole 50HP AC Three Phase Motor

Ask Lasest Price
Brand Name :	BM
Certification :	CE UL
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	10000pcs per month
Delivery Time :	10-25days

Add to Cart

Product Details
Company Profile

NEMA Premium Efficiency Motor 2 Pole 4 Pole 6 Pole 50HP AC Three Phase Motor

NEMA Premium Efficiency Design B 2/4/6pole 50HP Asynchronous Induction Electric AC Three Phase Motor

HP:1-300HP
RPM:1200&1800,3600 RPM
Frame:143T-449T
Protection:IP55
Class B Temp Rise
40ºC Ambient Temperature Rating
Class F Insulation
Stator Winding Tropicalization

HP	Voltage	HZ	POLES	RPM	Frame	Insulation Class	Enclosure Type	Service Factor
1	230/460	60	2	3600	143T	F	TEFC	1.15
1.5	230/460	60	2	3600	145T	F	TEFC	1.15
2	230/460	60	2	3600	145T	F	TEFC	1.15
3	230/460	60	2	3600	182T	F	TEFC	1.15
5	230/460	60	2	3600	184T	F	TEFC	1.15
7.5	230/460	60	2	3600	213T	F	TEFC	1.15
10	230/460	60	2	3600	215T	F	TEFC	1.15
15	230/460	60	2	3600	254T	F	TEFC	1.15
20	230/460	60	2	3600	256T	F	TEFC	1.15
25	230/460	60	2	3600	284TS	F	TEFC	1.15
30	230/460	60	2	3600	286TS	F	TEFC	1.15
40	230/460	60	2	3600	324TS	F	TEFC	1.15
50	230/460	60	2	3600	326TS	F	TEFC	1.15
60	230/460	60	2	3600	364TS	F	TEFC	1.15
75	230/460	60	2	3600	365TS	F	TEFC	1.15
100	230/460	60	2	3600	405TS	F	TEFC	1.15
125	230/460	60	2	3600	444TS	F	TEFC	1.15
150	230/460	60	2	3600	445TS	F	TEFC	1.15
200	460	60	2	3600	447TS	F	TEFC	1.15
250	460	60	2	3600	449TS	F	TEFC	1.15
300	460	60	2	3600	449TS	F	TEFC	1.15
350	460	60	2	3600	449TS	F	TEFC	1.15
400	460	60	2	3600	449TS	F	TEFC	1.15
475	460	60	2	3600	449TS	F	TEFC	1.15
500	460	60	2	3600	449TS	F	TEFC	1.15
1	230/460	60	4	1800	143T	F	TEFC	1.15

FAQ

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
