YB3 Low Noise Three Phase Explosion Proof Flameproof ATEX AC Asynchronous Induction Ex Electric Motor. for Enhanced Industrial Safety
1, It confirms to engergy saving standard stipulated in
GB18613-2012 Minimum Allowable Values and Grades of Energy
Efficiency for Small & Minumum Sized Three Phase Induction Motors.
2,YBX3/YBBP series 3 phase EX d proof motors are featured with high performace, reliability, small vibration and low noise, whose energy efficiency grade is Class 2 in CHINA, EFF1 in Europe. The motors also conform to IEC standard for its power rank and mounting dimension, as well as in line with DIN42673 in German and energy request of EPACT.
3, YBX3/YB3/YBBP series explosion-proof performance is in
accordance to the standards of GB3836.1-2010 Explosive Atmosphere
Part 1: Gerneral Requirements for Equipment, GG3836.2-2010
Explosive Atmosphere Part 2: Equipment Protected by Type D
flameproof Enclosure,and it also consistent with the stipulation of
IEC79-1, 4BS4683 and EN50018.
4, YBX3/YB3/YBBP motors explosion-proof grade is Ex db IIB T4 Gb,
Ex d IIC T4 Gb Ex tD A21 IP65 T130 With ATEX certificate.
YBX3/YB3/YBBP series EX d proof motor manufacturer made of
flameproof, suitable for explosive gas atmospheres in the
mechanical equipment of the power drive. Divided into Class I and
II, Class I: electrical equipment for coal mines, explosion-proof
mark for Ex d I; Class II: In addition to coal mine other than the
explosive gas environment, explosion-proof mark for the ExdIIAT
(1-4), Ex d IIB T (1-4), Ex d IIC T (1-4), the temperature group
T1, T2, T3, T4.
5, YBX3/YB3/YBBP series IEC explosion proof induction motors frame size range H80 ~ H355, power rating and installation dimensions in line with GB / T4772.1 / IEC 60072-1 and GB / T4772.2 / IEC 60072-2 standards.
| Type | Asynchronous flame proof motor | Cooling Method | IC411 |
| Phase | Three Phase | Protection Class | IP55 |
| Voltage | 380V, 660V, 380/660V/Customized | Insulation Class | F |
| Rated Output | 0.75-315kw (1-425HP) | No. of poles | 2-10 pole |
| Rated Frequency | 50Hz/60Hz | Duty | S1 |
|
|
